SUMMIT Rework Systems

With the largest installed base of rework systems in the world, VJ Electronix is confident that we can meet any rework need that you have. Our systems are designed to rework components ranging from 01005 all the way to 120mm and we have a large range of applications including connectors, package-on-package, RF shields, and more! High-level automation, intuitive software, and easy set up help minimize operator intervention and simplify your most difficult rework processes.

Ready to Install?

Call us to reserve (800) 858-9729
Email: electronixsales@vjt.com

Semi-Automated

Maximum Board Size: 455 x 610mm
Maximum Field of View: 50mm
Component Range:
0201 - Large Connectors

Semi-Automated

Maximum Board Size: 530 x 762mm
Maximum Field of View: 80mm
Component Range:
01005 - Large Connectors

Automated

Maximum Board Size: 530 x 762mm
Maximum Field of View: 80mm
Component Range:
01005 - Large Connectors

Semi-Automated

Maximum Board Size: 650 x 1200mm
Maximum Field of View: 90mm
Component Range:
01005 - Large Connectors

Automated

Maximum Board Size: 600 x 900mm
Automatic Alignment

Summit LT120

Semi-Automated

Maximum Board Size: 600 x 900mm (650 x 1200 mm optional)

Maximum Field of View: 120mm
